Touch Controlled Three Box Type Hot And Cold Impact Chamber Test Chambers For Testing Equipment

BOTO GROUP LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Touch Controlled Three Box Type Hot And Cold Impact Chamber Test Chambers For Testing Equipment

  • 1
  • 2
  • 3

Brand Name : BOTO

Certification : CE ISO900

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : T/T

Delivery Time : 10-15work days

Packaging Details : Plywood wooden case

External Materials : SUS#304 stainless steel

Customized Support : OEM, ODM

Safety Protection Device : Protection for leakage

Inner Box Volume : 49L

Voltage And Frequency : 380V±10% 50HZ

Internal Measurement : 40*35*35 CM

Low temperature range : -10~-60°C

High temperature range : +80~+200°C

Test temperature range : -40~+150°C

Recovery time : 3~5 minutes

Contact Now

Three box- type hot and cold impact chamber or temperature schock chamber

Product Description

Mainly used in national defense industry, aviation industry, automotive parts, electronic components, plastics industry, food industry and other related product development, straightening management engineering test specifications. The regenerative cold and hot shock tester is widely used in electronic parts, semiconductors, metals, chemicals, materials and other testing equipment. Its characteristics are as follows:

1. Touch-controlled color man-machine interface + PLC + J import temperature controller

2. Setting cycle and defrosting times;

3. Display of abnormal and fault points with simple teaching reminders for troubleshooting;

4. Comprehensive system safety protection and power outage memory;

5. Multiple safety protection: refrigerant high voltage protection, compressor overload protection, current overload protection, overtemperature protection, leakage protection

6. Air-cooled or water-cooled cooling can be selected according to customer's requirements.Touch Controlled Three Box Type Hot And Cold Impact Chamber Test Chambers For Testing Equipment

Applicable Industries:

Three Boxes Hot and Cold Impact Test Chamber Thermal Shock Machine used to test the material structure or composite material in an instant by the extremely high temperatures and very low temperature continuous environment which can endure the degree of order in the shortest possible time to test its thermal expansion and contraction caused by chemical changes physical harm.

The applicable the object material, including metals, plastics, rubber, electronic, ..., etc., can be used as the basis of its product improvement or reference.

Features:

1.Thermal shork chamber in each zone for peak demand of heating and cooling. Provides extra thermal energy to efficiently meet the MIL-STD 883 requirements.
2.Temperature recorder provides 24 hour part temperature recording as the load travels from zone to zone. Using touch-control graph control as operation interface, easy to operate.
3.The system can be used for automatic Circulation Shock or manual selective shock, capable of setting two zones or three zones shocks as well as cold and thermal shock start-up.
4.Custom-made and optional accessories available.

Corresponding Standard:

GB11158 GB10589-89 GB10592-89 GB/T10586-89 GB/T2423.22-2001 GB/T2423.1-2001 GB/T2423.2-2001 GB/T2423.3-93 GB/T2423.4-93 ASTM D1735 EIA - 364-59
IEC60068-2-1.1990 IEC60068-2-2.1974 IEC 68-2-30 IEC68-2-03 EIA - 364-31C

Touch Controlled Three Box Type Hot And Cold Impact Chamber Test Chambers For Testing Equipment

Product details

Inner tank volume 49L
Inner box size 40cm*35cm*35cm
Low temperature range -10~-60°C
High temperature range +80~+200°C
Test temperature range -40~+150°C
Recovery time 3~5 minutes
Temperature fluctuation ±2°C
Temperature uniformity ±2°C

FAQ

1. If I want to visit your factory, is the traffic convenient ?

Our company traffic is very convenient, it is only 10 minutes by car or taxi from our city light rail to our company, we also can arrange the shuttle bus for you to our factory.

2. Does your product have CE certification ?

Yes, we have the CE certification FCC,ISO,etc.

3. If there is not any size meet my need, can I customize?

Of course, we are the 20years factory that with rich experience in custom made service,not only can provide customiz serivice,but also can provide professional advice.

Touch Controlled Three Box Type Hot And Cold Impact Chamber Test Chambers For Testing Equipment

Touch Controlled Three Box Type Hot And Cold Impact Chamber Test Chambers For Testing Equipment
