Environmental Temperature Humidity Climatic Test Chamber

Name: Environmental Temperature Humidity Climatic Test Chamber
Brand: BOTO
Price: 1 USD

China Environmental Temperature Humidity Climatic Test Chamber factory

Brand Name : BOTO

Model Number : BT-NKHS-500-GDC

Certification : CE ISO

Place of Origin : China

MOQ : 1set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 200 Set/Sets per Month

Delivery Time : 5-25 days

Packaging Details : wooden case

Temperature Range : 0℃-150℃

Fluctuation/Uniformity : ±0.5℃/±2℃

Heating rate : 1℃/min-3℃/min

Sensors : Platinum resistance. PT100Ω/MV

Water supply system : Humidification water supply is automatically controlled

Power : Electronic

Humidity range : 20%R.H-98%R.H

Cooling rate : 0.7℃/min-1℃/min

Humidification system : all stainless steel shallow surface evaporative humidifier

Usage Environment temp : 5℃~+30℃ ≤85%R.H

Contact Now

Environmental Temperature Humidity Climatic Test Chamber

Factory direct and one-stop service

Product parameters

Temperature Range	0℃~150℃
Humidity range	20% R.H~98%R.H
Fluctuation/Uniformity	±0.5℃/±2℃
Heating rate	1℃/min~3℃/min
Cooling rate	0.7℃/min~1℃/min
Accuracy range	Setting accuracy: temperature 0.1℃, humidity 1% R.H, indication accuracy: temperature 0.1℃, humidity 1% R.H
Sensors	Platinum resistance. PT100Ω/MV
Humidification system	External isolation type, all stainless steel shallow surface evaporative humidifier
Dehumidification system	Using evaporator coil dew point temperature laminar flow contact dehumidification method
Water supply system	Humidification water supply is automatically controlled. And can recycle the remaining water. Save water and reduce consumption
Circulation System	Temperature-resistant and low-noise air-conditioning type motor. Multi-lobe centrifugal wind turbine
Standard configuration	1 set of illuminated glass window, 2 specimen holders, 1 test lead hole (25, 50, 100mm)
Security Protection	Leakage, short circuit, over temperature, water shortage, motor overheating, compressor over pressure, overload, over current protection/controller power failure memory
Voltage	AC110V/AV220V/AC380V/415V±10% 50±0.5Hz Three-phase five-wire system
Usage Environment temp	5℃~+30℃≤85%R.H

Product introduction

This product is simulated GB / T9596-2006 test box technical conditions GB / T9599-2009 low-temperature test box technical conditions GB / T 9592-2009 high and low-temperature test box technical conditions GB / T9159-2009 High temperature test box technical conditions

Mainly for aerospace, aviation, petroleum, chemical, military, automobile ( motorcycle ), ships, electronics, communications, and other scientific research and production units to provide temperature and humidity change environment, simulation test under the condition of temperature and humidity change environment loading simulation vibration adaptability test and the safety test of electronic components to provide reliability test, product screening.

All sizes of products can be customized.

Environmental Temperature Humidity Climatic Test Chamber

Temp and humidity range

Environmental Temperature Humidity Climatic Test Chamber

Company introduction

Environmental Temperature Humidity Climatic Test Chamber
