Temperature Stability Climatic Test Chamber

Name: Temperature Stability Climatic Test Chamber
Brand: BOTO
Price: 1 USD

China Temperature Stability Climatic Test Chamber factory

Brand Name : BOTO

Model Number : BT- HJ-7121

Certification : CE ISO

Place of Origin : China

MOQ : 1set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 Set/Sets per Month

Delivery Time : IN STOCK

Packaging Details : wooden case

Temp. range : -20ºC~150ºC

Power(KW) : 4.5

Weight(KG) : 150

Humidity uniformity : ±3.0%R.H

Heat up time : -20ºC~+100ºC,within 35 min

Pull down time : +20ºC~-20ºC, within 45 min

Standard accessories : Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m

Safety device (standard) : No fuse breaker, over pressureover heat and over current protection for compressor,

Control System : Balanced Temperature & Humidity Control System

Humidity Range : 20~98%R.H

Temp. constancy : ±0.5ºC

Humidity constancy : ±2.5%R.H

Temp. uniformity : ±2.0ºC

Interior material : Stainless Steel Plate(SUS 304)

Exterior material : Baked Painting Steel Or Stainless steel(SUS304)

Insulation material : Rigid polyurethane Foam and Glass Fiber Wool

Ambient Temp. : +5ºC~+35ºC

Wiring method : AC 380±10%50Hz ,3 phase 4 wires +Ground Wires

Contact Now

Temperature Stability Climatic Test Chamber

Product Description

New Design Temperature and Humdity Control Chamber Product Reliable Tester is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance, suitable for quality control of the industries of electron, electrical equipment, vehicle ect.

Featuers

1. Delicate touch and excellent user experience;
2. Unique and compact design, topgrade appearance, stable performance and easy operation;
3. Can simulate a wide range of temperature and humidity environments;
4. Capable of testing large components, assemblies, and finished products;
5. Customized sizes and configurations avaible;
6. One year warranty
7. Visually attractive with large windows
8. Space-saving and Compact with optimized test chamber volumes
9. Powerful, suitable for a broad range of applications involving temperature and relative humidity

Technical Parameter Environmental Temperature and Humidity Chamber

Secifications ( at +20ºC room temp. Or+25ºC water temp with empty load)
Model		BT-KMH-R series	BT-KMH-L series	BT-KMH-S series
		36R	36L	36S
Temp. range		-20ºC~150ºC	-40 ºC~+150ºC	-60ºC~+150ºC
Interior sizel	W(mm)	300	300	300
	H(mm)	400	400	400
	D(mm)	300	300	300
Exterior size	W(mm)	460	460	460
	H(mm)	780	780	780
	D(mm)	1020	1020	1020
Power(KW)		4.5	4.5	4.5
Weight(KG)		150	150	150
Humidity uniformity		±3.0%R.H	±3.0%R.H	±3.0%R.H
Heat up time		-20ºC~+100ºC,within 35 min	-40ºC~+100ºC, within 45 min	-60ºC~+100ºC,within85 min
Pull down time		+20ºC~-20ºC, within 45 min	+20ºC~-40ºC , within 60 min	+20ºC~-60ºC,within 80 min
Standard accessories		Sight window1, cable port(portΦ50mm)1, shelves2, chamber lamp1, power cable *2m
Safety device (standard)		No fuse breaker, over pressureover heat and over current protection for compressor,
		Over temp. protect, over load protect of blower, dry heat protection
Control System		Balanced Temperature & Humidity Control System
Refrigeration system		Air Cooled
		Hermetic compressor,Single stage refrigeration system
		CFC-Free refrigerant(HFC-507/HFC-23)
Controller		Panel:7-inch LCD Touch panel, Chinese or English display selectable
		Operation model :Program or fix point running
		Memory capacity :120programs,1200steps,
		All repeat 999 cycles, part repeat 99 cycles
Humidity Range		20~98%R.H
Temp. constancy		±0.5ºC
Humidity constancy		±2.5%R.H
Temp. uniformity		±2.0ºC
Interior material		Stainless Steel Plate(SUS 304)
Exterior material		Baked Painting Steel Or Stainless steel(SUS304)
Insulation material		Rigid polyurethane Foam and Glass Fiber Wool
Ambient Temp.		+5ºC~+35ºC
Wiring method		AC 380±10%50Hz ,3 phase 4 wires +Ground Wires
