1000L 504L Material SS 304 -70℃--150℃ Test Temperature Stability Temperature Humidity Test Chamber
Product description
The chambers are widely used for testing various types of materials, components and equipments
for their tolerance of heat, cold, dry and humidity. It is applicable for quality inspection of all
types of electronic products, electrical appliances and products from communication, automobiles,
plastics, metal, food, chemical, building materials, medical components and equipments and
aerospace spares and components.
Specification
| Model | BT-504 | BT1000 |
| Inner Dim(CM) | 70x90x80 | 100x100x100 |
| External Dim(CM) | 100x180x103 | 130x190x123 |
| Relative Humidity | 20%-90%RH |
| Temp Range | -70 ℃～150℃ |
| Heat -up time(min) | About 3-5℃/min |
| Pull-down time(min) | About 0.7℃-1℃/min |
| Temp fluctuation | ±0.5℃ |
| Temp uniformity | ±1.0℃ |
| Temp & Huni. Deviation | ±1.0℃/±3.0%RH |
| Interior | SUS 304 Stainless Steel Plate |
| Exterior | Coating or SUS 304 Stainless Steel Plate |
| Power Source | AC:220v/380v 50/60Hz |
Features
1.Working with TECUMSEH compressor and other advanced component to ensure the stability
of the colling system.
2.The controller can be connected to the computer through LAN interface. Users can design programs
on the computer screen,collect test data and records, call program execution, remote control machine
switch and other functions.
3.The use of multi-wing air supply fan strong air circulation, to avoid any dead angle, so that indoor
temperature and humidity distribution is uniform.
4.Complete safety protection device, if abnormal conditions occur, the controller screen will automatically
display the fault status, cut off the power switch, and provide troubleshooting methods.
Component & Spare Parts Used for the Chamber
TECUMSEH compressor DANFOSS Filter
DANFOSS expansion valve AIRMENDER Gas Liquid Separators
Packing & Delivery
1.Standard exported package: Internal anticollision protection, external export wooden box packaging.
2.Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3. Responsible for the damage during the shipping process, will change the damage part for you for free.
4.15-20days after confirming order,detail delivery date should be decided according to production season
and order quantity.
FAQ
Q1: How can i get a quotation?
A1: Kindly provide us your details request (inner chamber size, temperature range, humidity
range, power supply, product, etc.), leave us an inquiry or email and we will response promptly!
Q2: What's your temperature & humidity range?
A1: Our standards temperature range is -70℃~+180℃, 20%~98%RH.
We also can do Ultra low temperature to -190℃ .
Q3: What's your rate of heating & cooling?
A3: Our standards rate is average 3℃/min for heating, 2℃/min for cooling.
3℃/min,5℃/min,8℃/min,10℃/min,15℃/min linear or non-linear speed is available for us.
Q4: What's your warranty?
A4: 12 Months (Noted: free spares parts can be offered during warranty period, exclude consumables
and man-made damages), life-time technical service.
